Application Engineering
BULLETIN
AE4-1383 R5
© 2012 Emerson Climate Technologies, Inc.
Printed in the U.S.A.
Position 9 is not used
Node Addresses
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
1
2
3
4
5
6
7
8
9
1 2 3 4 5 6 7 8 9 10
9600 Even Network Terminated
Baud
Rate
Control
Mode
Parity
Network
Termination
19200
Not
Terminated
No
Parity
Stand
Alone
1 2 3 4 5
“On” (UP)
“Off ” (Down)
Figure 13 – K5 Communication Module DIP Switch Settings
Terminal 5, Demand Wire
Terminal 9, Jumper To
Terminal 13
Terminal 13, L1
and
Jumpered
to Terminal 9
Terminal 14, L2
Figure 14 – Wiring Relay Example
Figure 15 – E2 Jumpers
