Recommended Conguration
Component Description
TubingConguration Shock loop
Service Valve "Angled valve" fastened to unit
Suctionmufer Not required
Alternate Conguration
Component Description
TubingConguration Shock loop
Service Valve "Straight through" valve not fastened to unit
Mass/Suctionmufer May be required (acts as dampening mass)
Table 3
Design Congurations
Outdoor Ambient 85°F (29°C) 95°F (35°C) 105°F (40°C)
System On-Time (Minutes) 7 14 54
System Off-Time (Minutes) 13 8 6
Number of On/Off Cycles 5 5 4
Table 2
Field Application Test
