17
© 2016 Emerson Climate Technologies, Inc.
AEX-XXXX
PRELIMINARY
AE8-1384 R6
Figure 2 - CoreSense
Communications Module
View A
Terminal identification is from the end of the plug (View A)
Figure 3
Thermistor Circuit Cable
Scroll NTC Thermistor
(black wire)
Motor PTC Thermistor
(red wire)
Common Connection
(blue wire)
Spare Connection
