Emerson CORESENSE User Manual

9
© 2018 Emerson Climate Technologies, Inc.
AEX-XXXX
PRELIMINARY
AE8-1384 R6
Table 1
CoreSense Communications Module Part Numbers
Voltage
OEM Part Number
Service Part Number
24
571-0065-05
971-0065-04
120/240
571-0064-06
971-0064-05
Table 2
CoreSense Communications Module Specifications
Module Part Number
571-0065-05
571-0064-06
Module Voltage & Frequency
24 VAC, 50/60 HZ
120/240 VAC, 60HZ
115/230 VAC, 50 HZ
Allowable Voltage Range
18 - 30 VAC
85 - 265 VAC
T2/T1 Low Voltage Trip
18 VAC
85/170 VAC
T2/T1 Low Voltage Reset
19 VAC
95/185 VAC
Power Consumption
5 VA
5 VA
M1/M2 Contact Rating
2.5A Max
2.5A Max
Motor Temperature Trip Resistance
> 4.5KΩ ± 25%
> 4.5KΩ ± 25%
Open Motor Thermistor Trip Resistance
>220KΩ
>220KΩ
Shorted Motor Thermistor Trip Resistance
<40Ω
<40Ω
Temperature Reset Resistance
< 2.75KΩ
< 2.75KΩ
Scroll Temperature Trip Resistance
< 2.4KΩ
< 2.4KΩ
Open Scroll Thermistor Trip Resistance
>370KΩ
>370KΩ
Shorted Scroll Thermistor Trip Resistance
<1KΩ
<1KΩ
Scroll Temperature Reset Resistance
> 5.1KΩ
> 5.1KΩ
Reset Time After Trip
30 minutes
30 minutes
Operating Temperature
-40° to 150°F (-40° to 65°C)
-40° to 150°F (-40° to 65°C)
Storage Temperature
-60° to 175°F (-51° to 80°C)
-60° to 175°F (-51° to 80°C)
Table 3
CoreSense Communications Accessory Parts
Part Description
Part Number
Scroll/Motor Thermistor Harness
529-0102-00
