Emerson Crosby JLT*-JBS-E Series User Manual

16
D 1-4() N/A N/A N/A N/A N/A N/A N/A N/A
JOS D 5-7() N/A N/A N/A N/A N/A N/A N/A N/A
E 1-4() N/A N/A N/A N/A 11408429 0.117 11408440 0.100
F 1-4() N/A N/A 11408542 0.161 11408554 0.141 11408535 0.120
F 5-7() N/A N/A 11408542 0.161 11408554 0.141 11408535 0.120
G 11408534 0.225 11408818 0.199 11408819 0.173 11408536 0.146
H 11277099 0.274 11408828 0.241 11408829 0.208 11408830 0.174
J 11408532 0.342 11408839 0.299 11408840 0.257 11408842 0.215
K 11408854 0.407 11408855 0.356 11408856 0.306 11408858 0.255
L 1-4() 11408387 0.501 11408539 0.438 11408388 0.375 11408389 0.311
L 5-6() 11408401 0.514 11408402 0.451 11408403 0.388 11408404 0.324
M 11408410 0.560 11408417 0.486 11408419 0.416 11408420 0.345
N 11408434 0.608 11408435 0.530 11408436 0.453 11408437 0.375
P 11408452 0.735 11408453 0.640 11408454 0.546 11408455 0.451
Q 11408469 0.961 11408485 0.829 11408482 0.708 11408480 0.583
R 11408486 1.128 11408483 0.979 11408485 0.829 11408481 0.679
T 11408505 1.455 11408506 1.264 11408508 1.074 11408509 0.883
T2 11408488 1.435 11408489 1.237 11408490 1.040 11408491 0.843
V 11408514 1.772 11408515 1.528 11408516 1.285 11408517 1.041
W 11408523 2.246 11408524 1.935 11408526 1.624 11408527 1.312
D 1-4() 11408396 0.114 11408407 0.102 11408418 0.090
JOS D 5-7() 11408808 0.114 11408680 0.102 11408798 0.090
E 1-4() 11408451 0.084 11408462 0.067 11408473 0.051
JOS E 5-7() 11408786 0.084 11408775 0.067 11408750 0.051
F 1-4() 11408566 0.099 11408577 0.078 11408588 0.058
F 5-7() 11408566 0.099 11408577 0.078 11408588 0.058
G 11408820 0.120 11408821 0.093 11408823 0.066
H 11408831 0.141 11408832 0.108 11408834 0.075
J 11408844 0.172 11408845 0.130 11408847 0.087
K 11408859 0.204 11408860 0.153 11408861 0.103
L 1-4() 11408390 0.248 11408391 0.185 11408392 0.122
L 5-6() 11408405 0.261 11408406 0.198 11408408 0.135
M 11408421 0.274 11408422 0.203 11408423 0.132
N 11408438 0.297 11408439 0.219 11408441 0.141
P 11408456 0.357 11408537 0.262 11408457 0.168
Q 11408478 0.459 11408476 0.335 11408474 0.210
R 11408479 0.530 11408477 0.380 11408475 0.231
T 11408511 0.692 11408538 0.501 11408512 0.311
T2 11408492 0.645 11408493 0.448 11408494 0.250
V 11408518 0.798 11408520 0.554 11408521 0.310
W 11408528 1.001 11408529 0.690 11408530 0.379
D Thru J N/A N/A
K 11408853 0.025
L 1-4() 11408386 0.032
L 5-6() 11408386 0.032
M 11408416 0.035
N 11408433 0.039
P 11408450 0.047
Q 11408471 0.062
R 11408472 0.075
T 11408504 0.095
T2 11408487 0.099
V 11408513 0.122
W 11408522 0.156
CROSBY STYLE JOS-E, JBS-E, JLT*-JBS-E, JLT*-JOS-E VALVES
InstallatIon and MaIntenance InstructIons
TABLE 10- JOS/JBS RESTRICTED LIFT SS316 SPACER / J_S-RL SS316 SPACER
Orifice
Part number Height
[1]
(inches) Part number Height
[1]
(inches) Part number Height
[1]
(inches) Part number Height
[1]
(inches)
30% of full capacity 40% of full capacity 50% of full capacity 60% of full capacity
Orifice
70% of full capacity 80% of full capacity 90% of full capacity
Orifice 5% increment
NOTE
1. Tolerance of Spacer Height is +/-.005.
2. N/A = Not Applicable, does not exist.
