11
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: CF244 & CF252
Installation of Storage Bracket
for Remote Control
A storage bracket is provided for holding your remote
control when not in use. If you desire to use the
bracket, install it on a wall that is away from excess
heat or humidity (Figure 19).
Remote Control Procedures (continued)
Setting Operating Frequency of Remote Control
Figure 19
Figure 20
Your remote control has code switches which must be
set in one of 32 possible code combinations (Figure
18). The five levers (numbered 1, 2, 3, 4, and 5) on the
switches are factory-set in the ON (up) position.
Change the switch settings as follows (Figure 20):
1. Slide the five switch levers in the remote control to
your choice of ON (up) or down positions. Use a ball-
point pen or small screwdriver and slide the levers
firmly up or down.
2. When power is restored, push and hold the fan OFF
button ( ) for 3 to 5 seconds to set the code in the
receiver.
3. If airflow is desired in the opposite direction, press
the ( ) button on the remote control. The fan must
be operating at any speed for the reverse button to
function. The blades will turn in the opposite
direction and reverse the airflow.
4. To set the desired fan speed, press the ( ) button
to decrease the speed and the ( ) to increase the
speed. The LED display will light up to indicate the
new speed selected.
5. To turn the downlight on, press and release the ( )
button. The light will turn on at the light intensity
previously selected.
6. To vary the intensity of the light, hold the ( ) button
down until the desired light intensity is reached, then
release the button.
7. The sixth switch marked ON and I is for dimming
control of lights: Set switch to ON to allow for
dimming of the lights. Set switch to I for no dimming
of the lights such as for fluorescent bulbs.
