1.) PHONES Jack.
2.) Power ON/OFF Button.
3.) CD Button.
4.) TUNER Button.
5.) AUX. Button.
6.) VOLUME – Button.
7.) CD Control Buttons:
CD PLAY/PAUSE
CD STOP
R-SKIP /DOWN
F-SKIP /UP
8.) Multi-function LCD Display.
9.) CD Door.
10.) CD Door OPEN/CLOSE position.
11.) FM Wire Antenna.
12.) AUX Input Jacks. (On Back Panel)
13.) Speaker Terminals. (On Back Panel)
14.) VOLUME + Button.
15.) PRESET EQ Button.
16.) BAND Button.
17.) M-UP/REPEAT Button.
18.) MEMORY/CLOCK-ADJ.Button.
19.) Remote Sensor.
LOCATION OF CONTROLS AND INDICATORS
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
