CC7.5.1/0705/E
Technical Information
3.3 Fans used on units manufactured before 1994
If you have an "old" unit manufactured before 1994, some fans are not supplied anymore, but you can replace them
with the present fans.
You can find the equivalent in the following cross reference (table 3).
Fan characteristics
Blade φ mm
Motor
Q2 Q3 350 25W 1 Ph still supplied
Q3 Q4 T42 T43 T81 350 60W 3 Ph model 120 / 121
Q5 Q6 Q7 T5 T71 T82 356 60W 3 Ph model 120 / 121
Q8 Q10 Q12 T93 T94 T101 T121 T151 420 200W 3 Ph model 270 / 271
T17 U61 U121 500 700W 3 Ph still supplied
Old condensor Replacement fan
Table 3: Cross-reference: replacement fans
4 Fans for Copeland EazyCool outdoor condensing units
The OM and OL units are fitted with a single-phase fan since the beginning of 2003, earlier manufactured units are
provided with a three-phase fan, models 120 and 270 depending on the condensing unit model.
Current used fans (model 121 or 271) are interchangeable with the previous models, but the wiring has to be
changed to single-phase wiring.
The OMQ and OLQ have a low speed (910 rpm) 6 pole single-phase motor.
Today, the condensers of the OM, OMQ, OL and OLQ units are equipped with single-phase fan(s).
The fan model is given in our Product Selection Catalogues and in Copeland Selection Software, both available on
www.eCopeland.com.
4.1 Technical data
Blade
diamete
Power input Voltage
Motor
current
mm W V (±10%) / Ph / Hz EBM Rotomatika A Main Auxilary
121 350 117 220 - 240 / 1 / 50 0.54 72 108
271 420 300 220 - 240 / 1 / 50 5 / 400 6.3 / 400 1.35 25 88
65 350 78 220 - 240 / 1 / 50 2 / 400 3.15 / 400 0.31 143 159
145 420 155 220 - 240 / 1 / 50 4 / 400 6.3 / 400 0.67 45.9 51.6
301 500 290 220 - 240 / 1 / 50 1.7 24.7 33.3
8 / 400
Run capacitor
µF / V
Winding resistance
Ω
(±10%), 25°C
Fan model
4 / 400
Table 4: Technical data – fans for Copeland EazyCool condensing units
4.2 Wiring diagram
See figure 1.
Information in this document are subject to change without notification.
4/4
