Table 5-13. Transducer Block Parameter Definitions (Continued)
Label
PARAMETER_NAME
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Reserved A
RESERVED_A
80 RW ALL N/A SETUP
Data Type: Array, 118 x UINT8
Reserved
Reserved AI
RESERVED_AI
81 RW ALL 0 SETUP
Data Type: Uint16
Reserved
Upgrade Progress
UPGRADE_PROGRESS
82 RO N/A 1 N/A
Data Type: Enum
Not used by the DVC6000f
SPEC_SHEET_VALVE
83
Valve Size
VALVE_SIZE
83.1 RW ALL NULL ALL Data Type: Visible String
Valve Class
VALVE_CLASS
83.2 RW ALL NULL ALL Data Type: Visible String
Rated Travel
RATED_TRAVEL
83.3 RW ALL 0.00 ALL Data Type: Float
Actual Travel
ACTUAL_TRAVEL
83.4 RW ALL 0.00 ALL Data Type: Float
Shaft Stem Dia
SHAFT_STEM_DIA
83.5 RW ALL 0.00 ALL Data Type: Float
Packing Type
PACKING_TYPE
83.6 RW ALL NULL ALL Data Type: Visible String
Inlet Pressure
INLET_PRESSURE
83.7 RW ALL 0.00 ALL Data Type: Float
Outlet Pressure
OUTLET_PRESSURE
83.8 RW ALL 0.00 ALL Data Type: Float
SPEC_SHEET_TRIM
84
Seat Type
SEAT_TYPE
84.1 RW ALL NULL ALL Data Type: Visible String
Leak Class
LEAK_CLASS
84.2 RW ALL
ANSI Seat Leakage
Classification
1=I
2=II
3=III
4=IV
5=V
6=VI
7=BFW
8=STD AIR
1= I ALL Data Type: Enum
Port Diameter
PORT_DIAMETER
84.3 RW ALL 0.00 ALL Data Type: Float
Port Type
PORT_TYPE
84.4 RW ALL
1=balanced
2=unbalanced
1=balanced ALL Data Type: Enum
Flow Direction
FLOW_DIRECTION
84.5 RW ALL
1=up
2=down
1=up ALL Data Type: Enum
Push Down To
PUSH_DOWN_TO
84.6 RW ALL
1=open
2=close
2=close ALL Data Type: Enum
Flow Tends To
FLOW_TENDS_TO
84.7 RW ALL
1=open
2=close
1=open ALL Data Type: Enum
Unbalanced Area
UNBALANCED_AREA
84.8 RW ALL 0.00 ALL Data Type: Float
Trim Style 1
TRIM_STYLE_1
84.9 RW ALL NULL ALL Data Type: Visible String
Trim Style 2
TRIM_STYLE_2
84.10 RW ALL NULL ALL Data Type: Visible String
