Emerson Fisher Fieldvue DVC6010f User Manual

DVC6000f Series
March 2006
5-60
Table 5-13. Transducer Block Parameter Definitions (Continued)
Label
PARAMETER_NAME
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Temperature Units
TEMPERATURE_UNITS
89 RW ALL
C=1001
F=1002
F SETUP Data Type: Enum
Pressure Units
PRESSURE_UNITS
90 RW ALL
kPa=1133
bar=1137
psig=1143
inHg=1155
inH2O=1146
psig SETUP Data Type: Enum
Tvl Units
TVL_UNITS
91 RW ALL
cm=1012
mm=1013
in=1019
deg=1005
in SETUP
Data Type: Enum
Travel units for spec sheet
ACTUAL-TRAVEL and
RATED_TRAVEL only.
Length Units
LENGTH_UNITS
92 RW ALL
cm=1012
mm=1013
in=1019
in SETUP
Data Type: Enum
Not used for spec sheet
ACTUAL-TRAVEL OR
RATED_TRAVEL
Area Units
AREA_UNITS
93 RW ALL
cm
2
=1025
mm
2
=1027
in
2
=1030
in
2
SETUP Data Type: Enum
Spring Rate Units
SPRING_RATE_UNITS
94 RW ALL
N/m=1165
lb/in=1596
lb/in. SETUP Data Type: Enum
MAI_CHANNEL_MAP
95
Data Type:Uint16
This defines which transducer
block channels will be sent to each
of the 8 MAI channels. No scaling
or other conversion will be done.
Values will be sent in the currently
defined units. If set to 0, then no
output to MAI (status will be set to
BAD).
1=FINAL_VALUE
2=TRAVEL_TARGET
3=FINAL_POSITION_VALUE
4=TRAVEL
5=SUPPLY_PRESS
6=ACT_PRESS_A
7=ACT_PRESS_B
8=ACT_PRESS_DIFF
9=DRIVE_SIGNAL
10=TRAVEL_DEVIATION
11=TEMPERATURE
12=CYCLE_COUNT
13=TRAVEL_ACCUM
MAI Channel 1
MAI_CHANNEL_1
95.1 RW MAN 1 through 13 1 SETUP
MAI Channel 2
MAI_CHANNEL_2
95.2 RW MAN 1 through 13 2 SETUP
MAI Channel 3
MAI_CHANNEL_3
95.3 RW MAN 1 through 13 3 SETUP
MAI Channel 4
MAI_CHANNEL_4
95.4 RW MAN 1 through 13 4 SETUP
MAI Channel 5
MAI_CHANNEL_5
95.5 RW MAN 1 through 13 5 SETUP
MAI Channel 6
MAI_CHANNEL_6
95.6 RW MAN 1 through 13 6 SETUP
MAI Channel 7
MAI_CHANNEL_7
95.7 RW MAN 1 through 13 7 SETUP
MAI Channel 8
MAI_CHANNEL_8
95.8 RW MAN 1 through 13 8 SETUP
5
