Emerson FloBoss S600+ Specification Manual

FloBoss™ S600+ Flow Computer Modbus Specification Manual
D301904X012
June 2024
6
Modbus specification. The message terminates with the ASCII Modbus trailer
characters CR followed by LF.
Section 6. Implemented Modbus
Functions
Implemented Modbus functions include:

Function 1: Read Output Status

Function 2: Read Input Status

Function 3: Read Output Registers

Function 4: Read Input Registers

Function 5: Write Single Coil

Function 6: Write Single Register

Function 8: Loopback

Function 15: Write Multiple Coils

Function 16: Write Multiple Registers
Each of these functions is described in this section.
Notes
 These message formats exclude the message header (ASCII only), the CRC/LRC,
and message trailer (ASCII only) since these are specific to the data transfer mode.
 The Gould/Modicon Modbus protocol specifies the address range for each function
code. However. the FloBoss S600+ Modbus configuration is flexible in that it does
not have to adhere to these address ranges although they are stated below for
clarity.
6.1 Function Code 1: Read Output Status
Function code 01 reads the output coils (Gould/Modicon addresses 00001–09999), reading
up to 2040 coils per poll in non-extended mode. Refer to Section 7, Message Length Mode
for more information on non-extended and extended mode.
Poll Format
Address
1 byte
Function 1 byte
