FloBoss™ S600+ Flow Computer Modbus Specification Manual
D301904X012
June 2024
20
Value Description
1 Link disabled
2 Telemetry failed

[SLAVE CONTROL OBJ <KPINTARR Number>]
This command specifies the KPINTARR used to indicate if the link is enabled
or disabled. The first field of the KPINTARR refers to the first stream that
uses the link, the second field of the KPINTARR refers to the second stream
that uses the link, and so on.
Value Description
0 Link disabled
1 Link enabled

[SLAVE ADDRESS OBJ <KPINTARR Number>]
This command specifies the KPINTARR used to set the slave address that the
link will poll for.
The first field of the KPINTARR refers to the first stream that uses the link,
the second field of the KPINTARR refers to the second stream that uses the
link, and so on.
Notes
 For Station Gas Chromatographs, separate KPINTARR’s are used for Chromat A
and Chromat B so only the first field of each KPINTARR is used.
 If this object is configured, the addresses configured in the KPINTARR take
precedence over the values configured in the [SLAVES <A> <B> <C> <D>],
[MESSAGE ADDR:<addr> FUNC:<func> START:<start> NUM:<num>
TRIGGER:KPINT <n>] and [SLAVE ADDRESS <A>] settings.

[MESSAGE ADDR:<addr> FUNC:<func> START:<start> NUM:<num>
TRIGGER:KPINT <n>]
The message command defines a single message which the master task
performs. Any number of messages may be included. The master task
performs the messages according to their order in the file.
• <addr> is the Modbus slave address (0...255).
• <func> is the Modbus function code for the message.
• <start> is the data start address for the message.
• <num> is the number of addresses in the message.
• <n> is the database index for the KPINT trigger object used to control the poll.
