Application Guide Chapter 4
GFK-2928C Oct 2019
Toolchest Components 11
Place into Program Blocks
When function blocks are dragged from the Toolchest into the Program Blocks collection,
PAC Machine.
Edition may prompt for an entry into which a variable name must be provided.
Figure 9: PAC Machine Edition Form: Enter Variable Name
The blocks and corresponding entries are as follows:
Group03 – LDs
Variable Name Entry
<no name required>
IGB00
DEV
CR01
Group04 – LDs
Variable Name Entry
DBS
SW01
Aut_Sw
Group05 – LDs
Variable Name Entry
DB00
Group06 – LDs
Variable Name Entry
GBusses
