For product standards, general operating specifications, and installation requirements, refer to PACSystems RX3i System
Manual, GFK-2314.
EMC Installation Requirements
To meet EN 55011 and FCC Class A radiated emissions, the Control system in which the IC695PNC001
module is used shall be mounted in a metal enclosure when three or more IC695PNC001 modules are
used. All surfaces of the enclosure must be adequately grounded to adjacent surfaces to provide electrical
conductivity. Wiring external to the enclosure must be routed in a metal conduit or equivalent. The conduit
must be mounted to the enclosure using standard procedures and hardware to ensure electrical
conductivity between the enclosure and conduit.
When installing, operating, or maintaining the IC695PNC001, personnel must ensure any electrostatic
charge is discharged through the use of a grounded ESD strap or other means.
Installation Location
This product is intended for use with the RX3i system. Its components are considered open equipment
(having live electrical parts that may be accessible to users) and must be installed in an ultimate enclosure
that is manufactured to provide safety. At a minimum, the enclosure shall provide a degree of protection
against solid objects as small as 12mm (fingers, for example). This equates to a NEMA/UL Type 1 enclosure
or an IEC60529 IP20 rating providing at least a pollution degree 2 environment. For details about installing
RX3i rack systems, refer to PACSystems RX3i System Manual, GFK-2314.
