KTM POWDER DISCHARGE SYSTEM (PDS) METALTITE
®
BALL VALVES
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
SELECTION GUIDE
Example E0126 M K 62 BY A30 RF 200 PX
Valve code
E0105 Full bore, trunnion type, JIS 10K, ASME CL150, (DN 250 - 350)
E0106 Full bore, trunnion type, JIS 20K, ASME CL300, (DN 250 - 350)
E0125 Full bore, trunnion type, JIS 10K, ASME CL150, (DN 50 - 200)
E0126 Full bore, trunnion type, JIS 20K, ASME CL300, (DN 50 - 200)
E0108 Full bore, trunnion type, ASME CL600, (DN 50 - 350)
Sub code
M Metaltite
®
seat
Special feature
K Powder service
Body code
32 JIS SCS14A (316SS), ASTM CF8M (316SS)
62 JIS SCPH2, ASTM WCB
Trim code Ball Description Seat Packing Stem
BY SCS14A / SFNi CF8M / SFNi 316 SS Stellited RTFE SCM 435 ENP
BG SCS14A / SFNi CF8M / SFNi 316 SS Stellited Graphite SCM 435 ENP
WY SCS14A / WC CF8M / WC 316 SS WC RTFE SCM 435 ENP
WG SCS14A / WC CF8M / WC 316 SS WC Graphite SCM 435 ENP
Flange code
A15 ASME Class 150 J10 JIS 10K
A30 ASME Class 300 J20 JIS 20K
A60 ASME Class 600 JPI Also available
Connection code
RF Raised face (smooth finish 125 to 250 AARH)
RJ Ring joint
Size
50 DN 50 (NPS 2) 100 DN 100 (NPS 4) 200 DN 200 (NPS 8) 300 DN 300 (NPS 12)
80 DN 80 (NPS 3) 150 DN 150 (NPS 6) 250 DN 250 (NPS 10) 350 DN 350 (NPS 14)
Option code
PX Powder proof devices around seat and stem areas
NOTES
SFNi Nickel alloy overlay
ENP Electroless nickel plating
WC Tungsten carbide coating
2 SPECIFICATIONS
The safety of the valves and conformity with your equipment should be checked by the design
engineer or those who determine the specification based on the catalog or other technical data.
Upon arrival, the applicable conditions (temperature, pressure, fluid-characteristics,
environmental conditions, mounting gauge etc.) should be first checked to make sure they
are correct.
For the standard specifications, refer to the table below and the catalog.
