20070809 13-3 A81N0_01EL
C940 CAP POLYESTER FILM 0.22µF 50V J CA1J224SER04
C942 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
CONNECTORS
CN401 CONNECTOR PRINT OSU KW04-800-
0200
J30402KET001
CN402 CONNECTOR PRINT OSU KW04-800-
0200
J30402KET001
CN701 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN702 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN703 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN704 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN705 242 SERIES CONNECTOR
224202104W1
J322C04TG001
CN706 242 SERIES CONNECTOR
224202106W1
J322C06TG001
CN801A CONNECTOR PRINT OSU
008283021200000S+
J383C02UG004
CN802A CONNECTOR PRINT OSU
008283021200000S+
J383C02UG004
DIODES
D31 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D401 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D402 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D403 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D404 ZENER DIODE MTZJT-774.3B QDTB0MTZJ4R3
D408 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D409 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D410 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D411 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D412 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D413 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D414 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D415 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D416 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D417 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D418 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D419 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D420 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D421 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D422 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D423 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D501 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D502 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D503 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D504 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D507 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D509 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D510 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D511 ZENER DIODE MTZJT-7739B QDTB00MTZJ39
D512 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D513 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D516 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D518 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D519 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D523 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D524 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D562 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D563 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D568 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D569 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D570 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D605# DIODE 1N5397-B NDLZ001N5397
D606# DIODE 1N5397-B NDLZ001N5397
D607# DIODE 1N5397-B NDLZ001N5397
D608# DIODE 1N5397-B NDLZ001N5397
Ref. No. Mark Description Part No.
D609 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D611# ZENER DIODE MTZJT-7722B QDTB00MTZJ22
D612 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D613 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D614 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D616# ZENER DIODE MTZJT-7733B QDTB00MTZJ33
D624# ZENER DIODE MTZJT-7739B QDTB00MTZJ39
D702 ZENER DIODE MTZJT-773.9B QDTB0MTZJ3R9
D801 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D802 ZENER DIODE MTZJT-7712B QDTB00MTZJ12
D901 SCHOTTKY BARRIER DIODE ERC84-
009
QDLZERC84009
D902 RECTIFIER DIODE FR202-B/P NDQZ000FR202
D903 SCHOTTKY BARRIER DIODE ERC81-
004
QDPZERC81004
D904 ZENER DIODE MTZJT-7724B QDTB00MTZJ24
D906 SCHOTTKY BARRIER DIODE ERA81-
004Q
QDLZRA81004Q
D909 DIODE FR154 NDLZ000FR154
D910 DIODE 1ZC43(Q) QDLZ001ZC43Q
D911 SCHOTTKY BARRIER DIODE ERC81-
004
QDPZERC81004
D914 DIODE FR104-B NDLZ000FR104
D915 PCB JUMPER D0.6-P5.0 JW5.0T
D916 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D917 SCHOTTKY BARRIER DIODE ERA81-
004Q
QDLZRA81004Q
D918 PCB JUMPER D0.6-P10.0 JW10.0T
D919 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D922 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D925 ZENER DIODE MTZJT-7724B QDTB00MTZJ24
D926 A ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D926 B ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D927 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D928 ZENER DIODE MTZJT-7733B QDTB00MTZJ33
D929 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D930 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D932 DIODE FR154 NDLZ000FR154
D933 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D934 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D940 ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D942 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D947 PCB JUMPER D0.6-P5.0 JW5.0T
D948 PCB JUMPER D0.6-P5.0 JW5.0T
D951 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D952 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D956 ZENER DIODE MTZJT-7712B QDTB00MTZJ12
D957 ZENER DIODE MTZJT-773.9B QDTB0MTZJ3R9
D962 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D963 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
ICS
IC31 IC VIF/SIF M61116FP TF0G QSZBA0SHT034
IC61 IC EEPROM AT24C128N-10SU-1.8 S NSZBA0TAZ083
IC601# PHOTO COUPLER LTV817MCF NPECLTV817MF
IC801 IC AN17812A QSZBA0SMS017
IC851 IC MTS DECORDER AN5832SA-E1V QSZBA0TMS003
IC852 IC SWITCHING TC4052BF(ELNF) QSZBA0TTS162
IC904 VOLTAGE REGULATOR PQ070XF01SZH QSZBA0SSH054
IC905 IC VOLTAGE REGULATOR 5V
KIA7805API/P
NSZBA0SJY041
IC908 SHUNT REGULATOR KIA2431AP-AT/P NSZBA0TJY054
IC909 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC910 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC911 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC912 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
Ref. No. Mark Description Part No.
