Emerson LC195EM82 User Manual

20070809 13-4 A81N0_01EL
IC913 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
COILS
L21 PCB JUMPER D0.6-P5.0 JW5.0T
L22 INDUCTOR 100µH-J-26T LLAXJATTU101
L31 PCB JUMPER D0.6-P5.0 JW5.0T
L32 INDUCTOR 18µH-J-26T LLAXJATTU180
L61 PCB JUMPER D0.6-P5.0 JW5.0T
L63 PCB JUMPER D0.6-P5.0 JW5.0T
L66 INDUCTOR CHIP LK16081R0K-T 1.0µH LLACKB3TU1R0
L401B POWER INDUCTER RCR1616-471K LLC471KSF009
L403 CHOKE COIL 22µH-K LLBD00PKV021
L601# LINE FILTER 5.0MH 6Y075 LLBG00ZKT004
L701 PCB JUMPER D0.6-P5.0 JW5.0T
L702 INDUCTOR 22µH-J-26T LLAXJATTU220
L851 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q401 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q402 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q403 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q404 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q405 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q406 NPN TRANSISTOR POWER 2SC4881F
HFE MAX320
QQWZ2SC4881F
Q407 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q408# FET MOS SMD HAT2215R01-EL-E QF2ZHAT2215R
Q409 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q410 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q411 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q412 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q501 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q601# FET MOS 2SK3563(Q) QFWZ2SK3563Q
Q603# TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q707 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q708 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q709 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q802 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q901 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q902 NPN TRANSISTOR POWER 2SC4881F
HFE MAX320
QQWZ2SC4881F
Q905 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q906 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q907 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q908 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q909 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q910 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q913 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q916 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q917 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q918 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q919 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q922 NPN TRANSISTOR POWER 2SC4881F
HFE MAX320
QQWZ2SC4881F
Q923 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q924 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q925 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q926 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q927 NPN TRANSISTOR POWER 2SC4881F
HFE MAX320
QQWZ2SC4881F
Q928 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q929 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q930 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q932 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q933 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q934 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Ref. No. Mark Description Part No.
Q935 NPN TRANSISTOR POWER 2SC4881F
HFE MAX320
QQWZ2SC4881F
RESISTORS
R17 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R18 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R21 CHIP RES. 1/10W J 150k Ω RRXAJR5Z0154
R23 CHIP RES. 1/10W J 680 Ω RRXAJR5Z0681
R24 CHIP RES. 1/10W J 820k Ω RRXAJR5Z0824
R25 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R26 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R32 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R38 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R42 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R46 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R48 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R49 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R61 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R62 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R63 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R64 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R65 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R67 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R68 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R72 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R73 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R74 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R75 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R401 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
R402 CARBON RES. 1/4W J 27k Ω RCX4JATZ0273
R403 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R404 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R405 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R406 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R407 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R408 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R409 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R410 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R411 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R412 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R413 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R414 CHIP RES. 1/10W J 47 Ω RRXAJR5Z0470
R415 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R416 CARBON RES. 1/4W J 470 Ω RCX4JATZ0471
R417 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R418 CHIP RES. 1/10W J 330 Ω RRXAJR5Z0331
R419 CHIP RES. 1/10W J 330 Ω RRXAJR5Z0331
R420 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R421 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R422 CHIP RES. 1/10W J 820k Ω RRXAJR5Z0824
R423 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R424 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R425 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R426 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R427 CHIP RES. 1/10W J 560k Ω RRXAJR5Z0564
R428 CHIP RES. 1/10W J 560k Ω RRXAJR5Z0564
R429 CHIP RES. 1/10W J 820k Ω RRXAJR5Z0824
R430 CARBON RES. 1/4W J 3.3 Ω RCX4JATZ03R3
R431 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R432 CHIP RES. 1/10W J 820 Ω RRXAJR5Z0821
R433 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R434 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R435 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R436 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
Ref. No. Mark Description Part No.
