Emerson LD200EM8 Service Manual

1-1 A7440SP
SPECIFICATIONS
< LCD TV Section >
< TUNER >
VHF/UHF Input : 75 ohm Unbal., F type
Intermediate Freq. : Picture 45.75 MHz, Sound 41.25 MHz
< LCD PANEL >
< VIDEO >
< AUDIO >
All items are measured across 8 Ω load at speaker output terminal..
Description Condition Unit Nominal Limit
1. Video S/N 80dB dB --- >43
2. Audio S/N 80dB dB --- >45
Description Condition Unit Nominal Limit
1. Number of Pixels
Horizontal
Vertical
pixels
pixels
1024
768
---
---
2. Viewing Angle
Horizontal
Vertical
°
°
-60 to 60
-60 to 40
---
---
Description Condition Unit Nominal Limit
1. Over Scan
Horizontal
Vertical
%
%
5
5
---
---
2. Color Temperature
AT 80% WHITE FIELD
x
y
°K 11000
0.276
0.282
---
±0.005
±0.005
3. Resolution
Horizontal
Vertical
line
line
400
350
---
---
4. Brightness AT 100% WHITE FIELD cd/m
2
250 ---
Description Condition Unit Nominal Limit
1. Audio Output Power 10% THD: Lch/Rch W 1.0/1.0 0.8/0.8
2. Audio Distortion 500mW: Lch/Rch % 1.5/1.5 3.0/3.0
3. Audio Freq. Response
- 6dB: Lch
- 6dB: Rch
Hz
Hz
70 to 8 k
70 to 8 k
---
---
4. Audio S/N
VIDEO1
VIDEO2
dB
dB
---
---
>45/45
>45/45

Emerson LD200EM8 Specifications

General

Brand	Emerson
Model	LD200EM8
Category	TV DVD Combo
Language	English
