Liebert GXTMT Series Installation and User Manual
1-3 kVA UPS
Page ８ V2.11 Emerson Network Power
4. Installation
Unpacking and Inspection
1) Unpack the packaging and check the package contents. The shipping package contains:
z A UPS
z A user manual
z A communication cable
z A battery cable (for Long Runtime models only)
z A CD containing UPS Monitoring Software (WinPower)
2) Inspect the appearance of the UPS to see if there is any damage during transportation.
Do not turn on the unit and notify the carrier and dealer immediately if there is any
damage or lacking of some parts.
Input and output power cords and protective earth ground installation
1. Notes for installation
1) The UPS must be installed in a location with good ventilation, far away from water,
inflammable gas and corrosive agents.
2) Ensure the air vents on the front and rear of the UPS are not blocked. Allow at least
0.25m of space on each side.
3) Condensation to water drops may occur if the UPS is unpacked in a very low
temperature environment. In this case it is necessary to wait until the UPS is fully dried
inside out before proceeding installation and use. Otherwise there are hazards of electric
shock.
2. Installation
Installation and wiring must be performed in accordance with the local electric code and
the following instructions by professional personnel.
For safety, please cut off the mains power switch before installation. The battery
breaker also needs to be cut off if it is a long backup time model (“GXT-L” model).
1) Open the terminal block cover located on the rear panel of the UPS; please refer to
the appearance diagram.
2) For 1KVA UPS, it is recommended to select the 1.5mm
2
wire.
3) For 2/3KVA, it is recommended to select the 2.5mm
2
wire.
