Unidrive M200-201 Quick Start Guide 11
Issue Number: 6
Table 4-2 Braking resistor resistance and power rating (200 V)
Table 4-3 Braking resistor resistance and power rating (400 V)
* Resistor tolerance: ±10 %
Model
Minimum
resistance*
Ω
Instantaneous
power rating
kW
Continuous
power rating
kW
01200017
130 1.2
0.25
01200024 0.37
01200033 0.55
01200042 0.75
02200024
68 2.2
0.37
02200033 0.55
02200042 0.75
02200056 1.1
02200075 1.5
03200100 45 3.4 2.2
04200133
22 6.9
3.0
04200176 4.0
Model
Minimum
resistance*
Ω
Instantaneous
power rating
kW
Continuous
power rating
kW
02400013
270 2.3
0.37
02400018 0.55
02400023 0.75
02400032 1.1
02400041 1.5
03400056
100 6.1
2.2
03400073 3
03400094 4
04400135
50 12.2
5.5
04400170 7.5
Unidrive M200 201 Quick Start Guide English Iss6.book Page 11 Thursday, September 10, 2015 1:48 PM
