10
4. Method to reduce the gap between the door seal and the oven front surface.
(1) To reduce gap located on part ‘A’
• Loosen two screws on stopper hinge top, and then
push the door to contact the door seal to oven front
surface.
• Tighten two screws.
(2) To reduce gap located on part ‘B’
• Loosen two screws on stopper hinge under, and then
push the door to contact the door seal to oven front
surface.
• Tighten two screws.
(3) To reduce gap located on part ‘C’
• Loosen a screw on interlock switch assembly located
top of oven body.
• Draw the interlock switch assembly inward as possible to engage with hook on the door bottom.
• Tighten a screw.
(4) To reduce gap located on part ‘D’
• Loosen a screw on interlock switch assembly located bottom of oven body.
and (4) are same as step (3).
NOTE : A small gap may be acceptable if the microwave leakage does not exceed 4mW/cm
2
.
