14 Appendix 1 Technical Data
NetSure 211 C23 Embedded Power Supply System User Manual
Appendix 1 Technical Data
Table 1 Technical data
Parameter
category
Parameter
Description
Environmental
Operating temperature
-5°C ~ 40°C
Storage temperature
-40°C ~ 70°C
Relative humidity
≤ 90%RH
Altitude
≤ 2000m (derating is necessary above 2000m)
Pollution level
Level 2
Others
No conductive dust or erosive gases. No danger of explosion
AC input
Input phase voltage
220Vac
Input voltage range
90Vac ~ 290Vac
Input frequency
45Hz ~ 65Hz
Max input current
Single phase, input current of each rectifier ≤ 7A
Power factor
≥ 0.99
Over-voltage level
Level 2
DC output
Rated output voltage
-53.5Vdc
Output voltage range
-42.3Vdc ~ -57.6Vdc
Output current
40A
Total regulation
≤ ±1%
Efficiency
≥ 90%
Noise (peak-peak)
≤ 200mV
Weighted noise
≤ 2mV
AC input
alarm and
protection
AC input over-voltage
alarm point
Default: 280Vac ± 10Vac, cofigurable through monitoring module
AC input over-voltage
alarm recovery point
15Vac lower than the AC input over-voltage alarm point
AC input under-voltage
alarm point
Default: 180Vac ± 10Vac, configurable through monitoring module
AC input under-voltage
alarm recovery point
15Vac higher than the AC input under-voltage alarm point
AC input over-voltage
protection point
Default: 305Vac ± 5Vac
AC input over-voltage
protection recovery point
10Vac lower than the AC input over-voltage protection point
AC input under-voltage
protection point
Default: 80Vac ± 5Vac
AC input under-voltage
protection recovery point
15Vac higher than the AC input under-voltage protection point
DC output
alarm and
protection
DC output over-voltage
alarm point
Default: 57.6Vdc ± 0.2Vdc, configurable through monitoring module
DC output over-voltage
alarm recovery point
0.5Vdc lower than the over-voltage alarm point
DC output under-voltage
alarm point
Default: 45.0Vdc ± 0.2Vdc, configurable through monitoring module
DC output under-voltage
alarm recovery point
0.5Vdc higher than the under-voltage alarm point
BLVD point
Default: 43.2Vdc ± 0.2Vdc, configurable through monitoring module
Rectifier
Current sharing
The imbalance is better than ± 5% rated output current. Test current range: 10% ~
100% rated current.
The imbalance is better than ± 3% rated output current. Test current range: 50% ~
100% rated current
Derate by input (45°C)
Input voltage: 176Vac ~ 290Vac, rectifier max. output power: 50% rated power,
1000W
Input voltage: 90Vac ~ 176Vac, rectifier output power: linear derating power
