NetSure
™
-48V DC Power System
User Instructions, UM582127000 (Issue AD, January 20, 2014)
Spec. No: 582127000 Code: UM582127000
Model No: 721NPBB Issue AD, January 20, 2014
Figure 23. EIB (ACU+ Extended Interface Board) Connector Locations
Optional EIB Interface Board
(Top View)
Optional EIB Interface Board Assembly
SW1
J3 J4J2
J9J8J7J6J5
J5-J9
Wire Size Capacity: 16-26 AWG.
Recommended Torque: 2.2 in-lbs.
