Quick Start Guide Section 4
GFK-2893P Sep 2019
Mounting & Installation 19
4. Mounting and Installation
4.1 Protective Sheet Installation
➢ To install the protective sheet
1. Remove the protective film from the
QuickPanel
+
display screen.
2. Wipe the display unit of any dust or fingerprints.
3. Peel back a corner of the clear side of the
protective sheet.
4. Begin applying the corner to the display screen.
5. Slowly apply the rest of the protective sheet,
smoothing out as you go.
6. Peel the green curing film from the protective
sheet.
4.2 Mounting Location
When mounting the Quick Panel
+
Operator
Interface,
make sure the mounting area allows room to insert and
remove the SD card, cables, and mounting brackets.
Select a location that allows natural convection air flow
from bottom to top of the Quick Panel
+
enclosure. Do not
mount the Quick Panel
+
at an angle more than 30° from
the vertical, as illustrated in the following figure. Refer to
the section, Environmental Specifications.
