Emerson QuickPanel+ IC755C S12CD Series Quick Start Guide

Quick Start Guide Section 4
GFK-2893P Sep 2019
Mounting & Installation 27
Figure 4.15: IC755CxW07CDx/IC755CxS06RDx VESA
Mounting Holes
75
mm
75
mm
75 mm
(2.95 in)
75 mm
(2.95 in)
Figure 4.16: IC755CxSxxCDx VESA Mounting Holes
100 mm
100 mm
100 mm
(3.94 in)
100 mm
(3.94 in)
Note: For user manuals, product updates, and other
information, go to the Support website,
https://www.emerson.com/Industrial-Automation-
Controls/support and refer to Operator Interfaces and
PC.
