ROC364 Instruction Manual
3-31 Input and Output Modules Rev Jun/05
Analog Input Modules—Loop and Differential Common Specifications
SCALING RESISTOR
250 Ω (supplied) for 0 to 20 mA full scale. 100 Ω
for 0 to 50 mA (externally-powered only).
RESOLUTION
12 bits.
FILTER
Single pole, low-pass, 40-ms time constant.
CONVERSION TIME
30 µs typical.
VIBRATION
20 Gs peak or 0.06 in. double amplitude, 10 to
2,000 Hz, per MIL-STD-202 method 204
condition F.
MECHANICAL SHOCK
1500 Gs 0.5 ms half sine per MIL-STD-202 method
213, condition F.
CASE
Solvent-resistant thermoplastic polyester, meets
UL94V-0.
Dimensions are 15 mm D by 32 mm H by 43 mm
W (0.60 in. D by 1.265 in. H by 1.69 in. W), not
including pins.
ENVIRONMENTAL
Meets the Environmental specifications of the
ROC, in which the module is installed, including
Temperature, Humidity, and Transient Protection
specifications.
WEIGHT
37 g (1.3 oz).
APPROVALS
Approved by CSA for hazardous locations Class I,
Division 2, Groups A, B, C, and D.
