4.4 Connecting Communications Cards to Wiring
Signal wiring connections to the communications cards are made through the communications port
connector and through TELCO (RJ11) connectors supplied with certain modem cards. These
connections are summarized in Table 4-4 and detailed in Sections 4.4.1 to 4.4.5.

NOTE: Use a standard screwdriver with a slotted (flat bladed) 1/8" width tip when wiring all
terminal blocks.
Failure to exercise proper electrostatic discharge precautions (such as wearing a grounded wrist
strap) may reset the processor or damage electronic components, resulting in interrupted
operations.
Table 4-4. ROC300-Series Communications Card Signals
Comm Card
Port Pin
1 2 3 4 5 6 7 8 9
EIA-232 (RS-232) CARD DCD RX TX DTR COM DSR RTS CTS RI
EIA-422/485 (RS-422/485)
CARD, 422 Usage
RX– RX+ TX+ TX–
EIA-422/485 (RS-422/485)
CARD, 485 Usage
OUT– OUT+
RADIO MODEM RXA TXA COM PTT+ PTT–
LEASED-LINE MODEM,
COMM Port, 4-wire Private
Line
TIP2 RING2 RING1 TIP1
LEASED-LINE MODEM,
RJ11 Port, 2-Wire
TIP
(RED)
RING
(GRN)
N/A N/A N/A N/A
LEASED-LINE MODEM,
RJ11 Port, 4-Wire
TIP2
(BLK)
TIP1
(RED)
RING1
(GRN)
RING2
(YEL)
N/A N/A N/A N/A
DIAL-UP MODEM, RJ11
Port
RING
(RED)
TIP
(GRN)
N/A N/A N/A N/A
DIAL-UP MODEM, COMM
Port (output only for
analyzer)
SPK RXD TXD DTR COM RI
SHUT
DOWN
+5V DSR
