1 Description and specifications
1.1 Description
The Rosemount 222 toroidal flow through conductivity sensor measures conductivity in
highly conductive liquids up to 2 S/cm (2,000,000 μS/cm). A noninvasive flow through
design allows for in-line installations without any obstruction to sample and makes these
sensors ideal for use with viscous or fibrous liquids.
1.2 Unpacking and inspection
Complete the following steps when you unpack your instrument.
1. Inspect the shipping container. If there is damage, contact the shipper immediately
for instructions.
2. If there is no apparent damage, and remove the sensor.
3. Ensure that all items shown on the packing list are present. If items are missing,
contact your local Customer Care representative.
4. Save the shipping container and packaging.
They can be reused to return the sensor to the factory in case of damage.
1.3 Sensor Specifications
Sensor specificationsTable 1-1:
Sensor specification Description
Wetted materials Body materials either glass-filled PEEK, glass-filled Tefzel,
or unfilled Tefzel. Option -20 has EPDM gasket
Process connection -20: 5/8 in. 11 UNC, -21: 3/4 in. MNPT
Cable length 20 ft (6.1 m)
Maximum cable length 200 ft (61.0 m)
Weight/shipping weight 2 lb / 3 lb (1.0 kg / 1.5 kg)
Maximum operating temperature and pressureTable 1-2:
Body material option Maximum temperature Maximum pressure
Maximum pressure (for
CRN registration only)
-02 (Glass-filled PEEK
(standard temperature))
248 °F (120 °C) 295 psig (2135 kPa) 220 psig (1618 kPa [abs])
Description and specifications
Rosemount 228 Sensor 1
