Quick Start Guide
5.0 Verify transmitter configuration (optional)
Transmitters are shipped from Emerson fully configured per request or by the
standard factory default configuration. The configuration can be verified using
any HART capable configuration tool. Configuration instructions for the Field
Communicator are included in this step. See Rosemount 520 Reference Manual
for configuration instructions using AMS Device Manager or the Rosemount
Transmitter Interface Software (RTIS).
5.1 Verify configuration using the Field Communicator
A Rosemount 520 Device Driver (DD) must be installed on the Field
Communicator to verify configuration. Emerson recommends installing the latest
DD to access the complete functionality. Visit www.emerson.com
for more
information.
Fast Key sequences for the latest DD are shown below in Table 6. A check (
)
indicates the basic configuration parameters. At minimum, these parameters
should be verified as part of configuration and startup.
Table 6. Fast Key Sequences (Device Revision 2, DD Revision 1)
Function Fast Key sequence

Alarm and Saturation Levels 2, 2, 2, 5, 7

Damping 2, 2, 1, 1, 5

Range Values 2, 2, 2

Ta g 2, 2, 6, 1, 1

Units 2, 2, 1, 1, 4

Analog Output Alarm Direction 2, 2, 2, 5, 2
Transfer Function 2, 2, 1, 1, 6
Digital Zero Trim 3, 4, 1, 3
Upper Sensor Trim 3, 4, 1, 1
Lower Sensor Trim 3, 4, 1, 2
Scaled D/A Trim (4–20 mA Output) 3, 4, 2
Digital to Analog Trim (4–20 mA Output) 3, 4, 2
Date 2, 2, 6, 1, 5
Descriptor 2, 2, 6, 1, 6
Message 2, 2, 6, 1, 7
Long Tag 2, 2, 6, 1, 2
Scaled Variable 3, 2, 3
Burst Mode 2, 2, 4, 3
Rerange with Keypad 2, 2, 2, 1
Loop Test 3, 5, 1
Sensor Temperature/Trend 3, 3, 2
Simulate Digital Signal 3, 5, 2
Transmitter Security (Write Protect) 3, 4, 4, 1
