Emerson Rosemount 520 - Flange Size for Flange Mounting

Quick Start Guide
9
February 2019
Table 1. Flange Size for Flange Mounting
Standard D (mm) B (mm) K (mm) d x n (mm)
DN25 PN16 115 16 85 14 x 4
DN40 PN16 150 18 110 18 x 4
JIS25A—16K 125 14 90 19 x 4
JIS40A—16K 140 16 105 19 x 4
1-in. ANSI/150 108 16 79 16 x 4
1
1
/2-in. ANSI/150 127 17.5 98.6 16 x 4
