Quick Installation Guide
00825-0100-4662, Rev CC
December 2012
Rosemount 8732
22
Integral Mount Transmitters
The interconnecting wire harness for an integral mount transmitter is installed at the factory.
See Figure 18. Do not use cable other than that supplied by Emerson Process
Management, Rosemount, Inc.
Figure 18. 8732EST Integral Mount Wiring Diagram
