Table 2-1: Mechanical retrieval tool with a single service valve: main dimensions and
weight
Maximum
Device Length
(mm)
150 240 350 425 640 920 1170
Mechanical
Retrieval Tool
length
extended,
including the
single valve (C)
[mm]
1160 1340 1565 1710 2140 2700 3200
Removal
clearance with
the single valve
(C+A) [mm]
1460 1640 1865 2010 2440 3000 3500
Mechanical
Retrieval Tool
weight [kg]
23.5 25.5 27.5 29.5 34 40 45.5
Retriever kit
approximate
weight [kg]
including the
single valve (13
kg)
65 67 69 71 75 81 87
Table 2-2: Mechanical retriever tool with a double service valve: main dimensions
and weight
Maximum
Device Length
(mm)
150 240 350 425 640 920 1170
Mechanical
Retrieval Tool
length
extended,
including the
double valve
(C) [mm]
1328 1508 1733 1878 2308 2868 3368
Removal
clearance with
the double
valve (C+A)
[mm]
1628 1808 2033 2178 2608 3168 3668
Mechanical
Retrieval Tool
weight [kg]
23.5 25.5 27.5 29.5 34 40 45.5
