Emerson Tartarini B/240-FS Series - Dimensions and Weights

Type B/240
4
Figure 4. B/240 Series Dimensions (mm)
DIMENSIONS AND WEIGHTS
B/249 • B/249-AP B/242 • B/242-AP
FS VERSION FS VERSION
∅ 200
252 50
153
50
175
∅ 200
252 170
153
50 175
90
∅ 125
170
7513048
184
75
13048184
Weights:
B/242 • B242-AP: 3.5 Kg B/242-FS • B242-AP-FS: 7.5 Kg
B/249 • B249-AP: 4.5 Kg B/249-FS • B249-AP-FS: 8.5 Kg
Note: The regulator can be installed with vertical or horizontal orientation of the actuator.
