a) Right click on the THUM Adapter and select Configure.
b) When the menu opens, select Manual Setup from the window
on the left and select the Wired Device tab on the top.
c) Make sure the Time drop down menu at the bottom of the
page has Current selected.
d) Under the Voltage Drop drop down menu in the Smart Power
Options box, select Variable Voltage Drop.
e) Select the Apply button to make any changes. See Figure 10-1
Configuring fixed voltage drop mode using Field Communicator
a) When communicating to the THUM Adapter select:
Configure → Manual setup → Wired Device → Voltage
Drop Mode.
b) In the method select Variable Voltage Drop.
Function Fast Key sequence Menu items
Voltage Drop 2, 2, 2, 2 Voltage Drop
6. Remove loop from high alarm value.
Figure 10-1: AMS Device Manager Configure Screen
September 2020 Quick Start Guide
Quick Start Guide 31
