TS1 Series
Temperature Controls
Alco Controls
D A T A S H E E T
TS1__35038_EN_R05.doc 6 / 8 10.08.2011
Standard Temperature Controls
Temperature controls should be selected such, that the target
upper and lower setpoints fall well inside the adjustment range
and not at the end of the specified range.
Type
Part Adjustment
Range Lowest Factory Max. Temp. Sensor
No.
Upper
Setpoint
°C
Differential
Setpoint
K
Setpoint
°C
Setting
°C
Bulb
Temp.
°C
Charge Type
Thermostats TS1 Top Operated (with capillary type sensor)
Thermostats without Off-Switch
TS1-A2P 4 530 400 -30 … +15 1.5 … 16 -36 -1 / -6 +150 2m
TS1-A3P 4 356 700 -10 … +35 1.5 … 16 -23 +3 / -2 Vapour capillary
TS1-A1A 4 351 500 -45 … -10 -55 -18 / -20
+100 Adsorption bulb
TS1-A5F 4 458 400 +20 … +60 3 … 10 +10 +35 / +30
Thermostats with Off-Switch
TS1-B1A 4 366 700 -45 … -10 -55 -18 / -20 2 m
TS1-B2A 4 366 800 -30 … +15 1.5 … 16 -36 -1 / -6 +150 Vapour capillary
TS1-B3A 4 366 900 -10 … +35 -23 +3 / -2 and
TS1-B4F 4 367 000 -30 … +35 2.8 … 20 -35 +5 / 0 +100 Adsorption bulb
Room Thermostats TS1 Top Operated (with coil type sensor)
Room Thermostats without Off-Switch, including insulation console
TS1-A1E 4 362 800 -45 … -10 -55 -18 / -20 0 m
TS1-A2E 4 355 200 -30 … +15 1.5 … 16 -36 +4 / +2 +70 Vapour coil
TS1-A3E 4 355 300 -10 … +35 -23 +20 / +18
Room Thermostats with Off-Switch, including insulation console
TS1-B2E 4 344 400 -30 … +15 1.5 … 16 -36 +4 / +2 +70 Vapour 0 m
TS1-B3E 4 344 500 -10 … +35 -23 +20 / +18 coil
Frost Monitors TS1 Top Operated (with capillary type sensor)
Frost Monitors without Off-Switch
TS1-C0P 4 352 100 +4.5 … +20 2.5 fix +2 4.5 / +2 6 m
TS1-D0P 4 352 200 +4.5 … +20 man. reset +2 +2 +150 Vapour capillary
Low temp. cut out
ca. 2.5 fix
