Emerson TS1 Series Datasheet

TS1 Series
Temperature Controls
Alco Controls
D A T A S H E E T
TS1__35038_EN_R05.doc 7 / 8 10.08.2011
Type
Part Adjustment
Range Lowest Factory Max. Temp. Sensor
No.
Upper
Setpoint
°C
Differential
Setpoint
K
Setpoint
°C
Setting
°C
Bulb
Temp.
°C
Charge Type
Thermostats TS1 Front Operated (with capillary type sensor)
Thermostats without Off-Switch
TS1-E1A 4 361 000 -45 … -10 2 … 16 -55 -18 / -20
TS1-E2A 4 356 200 -30 … +10 1.5 … 15 -36 +4 / +2 +150 Vapour
TS1-E3A 4 365 200 -10 … +25 1.5 … 15 -23 +3 / -2 2 m
TS1
-
E4F
4 367 500
-25 … +30 2.8 … 20 -30 +5 / 0 capillary
Defrost- and Universal Thermostat
and
TS1-E5F 4 338 100 +20 … +60 3 … 10 +10 +35 / +30 +100 Adsorption bulb
TS1-E7F 4 367 600 +0 … +10 2.5 fix -2.5 +5.5 / +3
Milk and beer Cooler Thermostat
Thermostats with Off-Switch
TS1-F1A 4 367 100 -45 … -10 2 … 16 -55 -18 / -20 2 m
TS1-F2A 4 367 200 -30 … +10 1.5 … 15 -36 -1 / -6 +150 Vapour capillary
TS1-F3A 4 367 400 -10 … +25 1.5 … 15 -23 +3 / -2 and bulb
Room Thermostats TS1 Front Operated (with coil type sensor)
Room Thermostats without Off-Switch, including insulation console
TS1-E1E 4 365 300 -45 … -10 2 … 16 -55 -18 / -20 0 m
TS1-E2E 4 356 800 -30 … +10 1.5 … 15 -36 +4 / +2 +70 Vapour coil
TS1-E3E 4 356 900 -10 … +25 1.5 … 15 -23 +20 / +18
Room Thermostats with Off-Switch, including insulation console
TS1-F1E 4 368 000 -45 … -10 2 … 16 -55 -18 / -20
TS1-F2E 4 368 100 -30 … +10 1.5 … 15 -36 +4 / +2 +70 Vapour 0 m
TS1-F3E 4 368 200 -10 … +25 1.5 … 15 -23 +20 / +18 coil
Thermostats TS1 for Flush Mounting (with coil type sensor)
Thermostats for Flush Mounting without Off-Switch
TS1-G2A 4 355 400 -30 … +15 1.5 … 15 -36 +4 / +2 +150 Vapour 2 m
TS1-G3A 4 364 800 -10 … +35 1.5 … 15 -23 +20 / +18 capillary
TS1-G4F 4 355 600 -30 … +35 2.8 … 20 -35 +5 / 0 and
Defrost- and Universal Thermostat
+100 Adsorption bulb
TS1-G7F 4 356 000 0 … +10 2.5 fix -2.5 +5.5 / +3
Milk and beer Cooler Thermostat
Thermostats for Flush Mounting with Off-Switch
TS1-H1A 4 364 600 -45 … -10 1.5 … 15 -55 -18 / -20
TS1-H2A 4 355 500 -30 … +15 1.5 … 15 -36 -1 / -6 +150 Vapour 2 m
TS1-H3A 4 367 900 -10 … +35 1.5 … 15 -23 +3 / +2 capillary
TS1-H4F 4 355 800 -30 … +35 2.8 … 20 -35 +5 / 0 and
TS1-H7F 4 365 500 0 … +10 2.5 fix -2.5 +5.5 / 3 +100 Adsorption bulb
Milk and beer Cooler Thermostat
