Emerson Unidrive M100 Quick Start Guide

8 Unidrive M100-101 Quick Start Guide
Issue Number: 6
Figure 3-1 Feature diagram (size 2 shown)
6
8
9
5
7
12
4
1
3
2
11
10
2
Key
1. Rating label (On side of drive)
2. Identification label
4. Relay connections
5. Control connections
6. Braking terminal
7. Internal EMC filter screw
8. DC bus +
9. DC bus -
10. Motor connections
11. AC supply connections
12. Ground connections
Unidrive M100 101 Quick Start Guide English Iss6.book Page 8 Wednesday, September 9, 2015 4:07 PM

Emerson Unidrive M100 Specifications

General

Brand	Emerson
Model	Unidrive M100
Category	Controller
Language	English
