14
a) Transformer connected meter
DANGER!
Contact with live parts is dangerous to life!
y The voltage taps are not fused within the meter and are directly
connected to the mains potential.
y Protect meters with a transformer connection in the voltage circuit
with a back-up fuse of ≤ 6 A.
y Load the voltage taps with 0.5 A max.
Transformer con-
nected meter
Current and voltage
terminals
Additonal terminals
Terminal dimension
W x H or d (mm)
5,0 x 5,5 2,6 x 2,2
Minimum connection
cross section (mm²)
2,5 1,0
Maximum connection
cross section (mm²)*
6,0 2,5
Maximum torques for
terminals (Nm)
1,2 --
Screw type Screw and washer
assembly with cross
recess, Type PZ1
(acc. to ISO 4757)
Spring loaded terminal
Thread size M5 —
Stripping length (mm) 10,0 5,0
* Rated connection capacity acc. to EN 60999-1
DANGER!
Risk of danger to life due to high voltage when current transform-
ers are interrupted!
The high voltage on the interrupted current transformer at the trans-
former connected meter is extremely dangerous and destroys the
current transformer.
y Short-circuit the secondary circuits of the current transformer at the
testing terminals before disconnecting the current path.
EMH metering
GmbH & Co. KG
Neu-Galliner Weg 1 • 19258 Gallin
GERMANY
Tel. +49 38851 326-0
Fax +49 38851 326-1129
E-Mail info@emh-metering.com
Web www.emh-metering.com
Tel. +49 38851 326-1930 (Support technique)
E-Mail support@emh-metering.com
Manuel d’instructions
LZQJ-XC
Compteur numérique 4 quadrants
FR
Etat du: Septembre 2020 Modications techniques sous réserves!
Contenu de la livraison
...........................................................................2
Remarques importantes
........................................................................2
Groupe cible .......................................................................................2
Utilisation conforme à la destination
...................................................2
Consignes de maintenance et conditions de garantie ........................2
Remarques sur l’entretien et la mise au rebut
....................................3
Consignes générales de sécurité
.......................................................4
Éléments du boîtier, de l’achage et de commande ..............................7
Plaque signalétique
............................................................................8
Achages à cristaux liquides
...........................................................10
Installation et mise en service
..............................................................13
a) Compteur avec raccordement transformateur ..............................16
b) Compteur pour raccordement direct jusqu’à 60 A ........................18
c) Compteur pour raccordement direct jusqu’à 100 A ......................19
Couvre-bornes ..................................................................................21
Batterie de lecture (facultatif) ............................................................21
Registre de contrôle d’installation C.86.0 .............................................22
Registre de défauts F.F ........................................................................24
Signication du drapeau de défaut: ..................................................24
Abréviations ..........................................................................................26
Déclaration de conformité CE pour LZQJ-XC ......................................27
LZQJXC-BIA-FR-2.50
