Big Star SENTO, Big Star SENTO MAX, V 1.0
Chassis
1 A) Assembly of the chassis - Big Star
SENTO
1. Unfold the rear legs
2. Make sure the indicator is completely
green.
3. Make sure the automatic safety lock is
in it´s lower activated position.
4. Pull out the telescopic handle. Make
sure that the handlebar is at the same
height on both sides before you lock
into position.
5. Lock the Telescopic locks on both
sides. Make sure the Telescopic locks
are properly locked with a ”click”.
6. Press the handle buttons on the
inside of the handlebar and unfold
the handle. Make sure they click into
position.
WARNING
• There must not be a child in the pram
when it is folded or unfolded
• Avoid having children in the vicinity
when the pram is folded or unfolded.
• Ensure that children are kept away
from all moving parts of the pram to
avoid risk of injury.
1 B) Assembly of the chassis - Big star
SENTO MAX
1. Slide the safety handle all the way to
the side (See arrow 1 located on the
safety handle). Maintain the position
and rotate the safety handle all the
way (See arrow 2 located on the safety
handle)
2. Unfold the rear legs
3. Press the bar in the middle of the
chassis until you hear a clear ”click”.
Make sure left and right side ”Click” in
properly. Make sure that you now see
the closed padlock. If the open padlock
is visible, the chassis is NOT locked.
WARNING
• ALWAYS check before use that the
chassis is locked. The closed padlock
will be shown.
• If the open padlock icon is visible,
press down on the metal bar, the
chassis locks and you will hear ‘click’
• Never use the stroller if the symbol
with the open padlock is visible.
4. Pull out the telescopic handle. Make
sure that the handlebar is at the same
height on both sides before you lock
into position.
5. Lock the Telescopic locks on both
sides. Make sure the Telescopic locks
are properly locked with a ”click”.
6. Press the handle buttons on the
inside of the handlebar and unfold
the handle. Make sure they click into
position.
WARNING
• There must not be a child in the pram
when it is folded or unfolded
• Avoid having children in the vicinity
when the pram is folded or unfolded.
• Ensure that children are kept away
from all moving parts of the pram to
avoid risk of injury.
2) Rear Wheels
Assemble of the rear wheels
1. Assemble the locking clip on the rear
wheel. Place the clip in open position.
2. Put the wheel shaft in position and lock
by the clip.
3. Assemble the rear wheel cover cap.
Assemble the rear wheel to the chassis
4. Wipe dirt from the wheel shafts before
you put on the wheels. Make sure the
rear wheel lock is in the open position,
marked red.
5. Place the wheel on the chassis and lock
with the wheel lock.
WARNING
• Ensure the wheel shaft is locked with
the locking clip before the wheel
