34
Big Star SENTO, Big Star SENTO MAX, V 1.0
cover cap is attached.
• The wheel cover cap must be
attached before use
• Check that the rear wheel is attached
to the chassis properly by pulling the
wheel. Repeat on both sides. The red
mark must not be shown.
Remove the rear wheels from the
stroller
6. Open the rear wheel lock and remove
the rear wheel.
Deassemble the rear wheel
7. Remove the wheel cover cap by
pressing the hooks inwards.
8. Place the locking clip in open position
and remove the wheel shaft.
3) Front Wheels
Assemble of the front wheels
1.Press the front wheel lock and push
the front wheel in place. Release the
lock and make sure the front wheel
is attached to the chassis properly,
by pulling the wheel. Repeat on both
sides.
2. Press the front wheel lock and remove
the wheel.
360° rotation/ locked rotation
3. The wheels can rotate freely through
360° when the locking ring is in its
upper position. The wheels can be
locked by pressing the locking ring
when the wheels are in the ”forward
facing” position.
4. The front wheels can be locked in a
forward position. This position of the
front wheels shall only be used when
the pram is parked. Never push the
pram with the wheels locked in forward
position.
WARNING
• Ensure that children are kept away
from all moving parts of the pram to
avoid risk of injury.
• 5. Never pull the pram when the
swivel wheels are unlocked. The pram
may wobble which can lead to a safety
risk if you are not cautious and careful.
• This product is not suitable for
jogging, skating or rollerblading.
4 A) Folding the chassis - Big Star
SENTO
1. Remove the Bassinet/Seat unit/
Accessories
2. Open both the telescopic locks on the
telescopic handles. Push the telescopic
handle down to its lowest position.
3. Adjust the angle of the handlebar by
pressing the Handle bar buttons on
the inside of the handlebar. Keep
the buttons pressed and adjust to the
lowest position.
4. Lift the Automatic safety lock and fold
the stroller with the folding handle.
5. If you want to make the chassis more
compact, you can remove the wheels.
WARNING
• There must not be a child in the pram
when it is folded or unfolded
• Avoid having children in the vicinity
when the pram is folded or unfolded.
• Ensure that children are kept away
from all moving parts of the pram to
avoid risk of injury.
4 B) Folding the chassis - Big star
SENTO MAX
1. Remove the Bassinet/Seat unit/
Accessories
2. Open both the telescopic locks on the
telescopic handles. Push the telescopic
handle down to its lowest position.
3. Adjust the angle of the handlebar by
pressing the Handle bar buttons on
the inside of the handlebar. Keep
the buttons pressed and adjust to the
lowest position.
4. Slide the safety handle all the way to
the side (See arrow 1 located on the
safety handle). Maintain the position
and rotate the safety handle all the
way (See arrow 2 located on the safety
handle). Lift the safety handle rmly
upwards and the stroller folds.
