38
Solo, Sento, Sento PRO V 1.1
Seat unit (ERGO & FLAT)
1) Assembly of the seat unit
ERGO
1. Seat Frame. Press both buttons on the
sides of the footrest to unfold.
2. Fold out both seat attachments.
3. Place the seat fabric cover over the top
edge of the seat frame.
4. - 4.1 Thread the harness strap through
the seat fabric and then place the seat
fabric around the seat plate. Close
the fabric underneath the seat with the
Velcro.
5. Position the safety straps around the
frame and click into the buckle on the
back of the backrest. Repeat on the
left and right side of the frame.
6. Fasten the press studs that secure the
fabrics to the frame on both sides.
7. Click the back rest adjustment handle
into the bracket on both sides.
8. Thread the strap through the hole in
the fabric and fasten around the back
rest adjustment handle with the press
stud.
9. Insert the bumper bar into the brackets
on both sides of the seat unit.
10. Fasten the crotch strap around the
front bar.
11. Attach the hood onto the seat frame
tubes at both sides. WARNING - Pinch
point - Danger of trapping.
12. Pull the fabric over the top of the seat
frame and secure with the lower press
stud. Repeat for the left and right sides.
Please note: If the hood moves up and
down on the seat frame tube this can
cause scratches. Ensure the seat frame
tube is free from dust and dirt.
FLAT
1. The seat unit is delivered fully
assembled. Only the bumper bar and
the hood need to be assembled. Insert
the bumper bar into the brackets on
both sides of the seat until you hear a
click.
2. Fasten the crotch strap around the
bumper bar.
3. Insert the hood in both sides of the
seat until you hear a click.
4. Secure the back of the hood by
using the 2 hooks. You can click
Emmaljunga’s footmuff (accessory) into
place using the eyelets/D-rings behind
the backrest.
WARNING
• Ensure that children are kept away
from all moving parts of the stroller to
avoid risk of injury.
• It is important that the seat unit fabric
is always correctly tted
• Never use the stroller without making
sure the seat unit fabric is correctly
assembled on the frame rst.
• The bumper bar should always be
tted when using the seat unit.
• Always check that the bumper bar
is correctly attached to the seat unit
before use.
• The hood should always be
assembled when the stroller is in use.
• Never carry the seat unit/stroller by
the bumper bar.
2) Attach/remove the seat unit
1. Engage the brake. Click the seat unit
into the chassis, make sure it clicks
in properly and securely on both
sides. The seat unit can be attached
in the direction of travel or against
the direction of travel. Make sure the
indicator is completely green.
2. Pull both handles on the sides upwards
and lift the seat unit off the chassis.
WARNING
• Ensure that children are kept away
from all moving parts of the pram to
avoid risk of injury.
• Always check that the seat unit is
securely xed to the chassis before
the pram is used.
• Hold the carrying handles until the
seat unit is in place.
• Never leave a child in the seat unit
when removing/attaching the seat
