68 Software index Emotron AB 01-3990-11r3
6- Jog, and Preset (MFIT) Frequency Setting on Keypad
7- Analog Input Signal Operation
Note: Group 7 is available when 5-06=0023 (AIN term.=Analogue input)
Function
Code no.
Description Range/Code
Factory
setting
Re-
marks
6-00 Keypad Frequency (Hz) 0.00 to 650.00 5.00 *1
6-01 Jog Frequency (Hz) 0.00 to 650.00 2.00 *1
6-02 Preset Speed #1 (Hz) 0.00 to 650.00 5.00 *1
6-03 Preset Speed #2 (Hz) 0.00 to 650.00 10.00 *1
6-04 Preset Speed #3 (Hz) 0.00 to 650.00 20.00 *1
6-05 Preset Speed #4 (Hz) 0.00 to 650.00 30.00 *1
6-06 Preset Speed #5 (Hz) 0.00 to 650.00 40.00 *1
6-07 Preset Speed #6 (Hz) 0.00 to 650.00 50.00 *1
6-08 Preset Speed #7 (Hz) 0.00 to 650.00 60.00 *1
Function
Code no.
Description Range/Code
Factory
setting
Re-
marks
7-00 AIN Gain (%) 0 to 1000 100 *1 *10
7-01 AIN Bias (%) 0 to 100 0 *1
7-02 AIN Bias Selection
0000: Positive
0001: Negative
0000 *1
7-03 AIN Slope
0000: Positive
0001: Negative
0000 *1
7-04
AIN Signal Verification Scan
Time (AIN, AI2) (ms x 2)
1 to 100 50
7-05 AI2 Gain (%) (S6) 0 to 200 100 *1
