Emotron AB 01-3990-11r3 Software index 69
8- Multifunction Output Relays and Output Signal
Operation
Function
Code no.
Description Range/Code
Factory
setting
Re-
marks
8-00
Analogue Output
Voltage Mode
(0 to 10 VDC, Term.
FM+)
0000: Output Frequency
0001: Frequency Setting
0002: Output Voltage
0003: DC Voltage
0004: Output Current
0005: PID Feedback *7
0000 *1
8-01
Analogue Output
Gain (%)
0 to 200 100 *1
8-02
Output Relay R1
Operation Mode
0000: Run
0001: Frequency Reached
(Frequency Command) (Set
Frequency ±8-05)
0002: Set Frequency (8-04 ±8-05)
0003: Frequency Threshold Level
(>8-04) - Frequency Reached
0004: Frequency Threshold Level
(<8-04) - Frequency Reached
0005: Over torque Threshold Level
0006: Fault
0007: Auto Restart
0008: Momentary AC Power Loss
0009: Emergency Stop Mode
0010: Coast-to-Stop Mode
0011: Motor Overload Protection
0012: Drive Overload Protection
0013: PID Feedback Signal Loss
0014: PLC Operation
0015: Power On *7
0006
8-03
Output Relay R2
Operation Mode
0000
8-04
Frequency Reached
(Hz)
(Refer to 8-02:
0001)
0.00 to 650.00 0.00 *1
8-05
Frequency Reached
Bandwidth (±Hz)
0.00 to 30.00 2.00 *1
