5. Lift the inside glass upwards as shown in the figure.
6. Remove the inside glass and you can see the middle glass.
REPLACING THE OVEN LIGHT
Ensure that the appliance is switched off before replacing the lamp to avoid
the possibility of electric shock
1.Disconnect the oven from the power supply by means of the omni polar switch used to connect the appliance to
the electrical mains; or unplug the appliance if the plug is accessible;
2.Remove the glass cover of the lamp-holder;
3.Remove the lamp and replace with a lamp resistant to high temperatures (570℉)with the following
characteristics:
Voltage: 120V 60Hz
Wattage: 25W
Type: G9
4.Replace the glass cover and reconnect the oven to the mains power supply.
