EMPHASER EA2260S User Manual

7
2. CONNECTIONS & CONTROLS
2.1 REAR PANEL EA2160s/EA2260s
9 “OUTPUT TERMINALS”
Loudspeaker output terminal to connect the loudspeakers.
10 “GND” POWER INPUT TERMINAL
Moulded direct power input terminals to connect the amplifier to the negative or ground
wire of the vehicle.
11 “REMOTE” INPUT TERMINAL
Terminal to connect the amplifier to the automatic (remote) turn-on / turn-off lead of the
head unit.
12 “+12V” POWER INPUT TERMINAL
Moulded direct power input terminals to connect the amplifier to the positive +12V power
wire connected to the car battery.
bn bm bl9
bnbl bm 9
EA2160s
EA2260s
