2. CONNECTIONS & CONTROLS
2.2 REAR PANEL EA4160s
12 SPEAKER OUTPUT TERMINALS 1/2-CH and 3/4-CH
Output terminals to connect the speakers in stereo or bridged mode to the amplifier.
13 „GND“ POWER INPUT TERMINAL
Terminal to connect the amplifier to the negative or ground pole of the car battery.
14 „REM“ REMOTE INPUT TERMINAL
Terminal to connect the amplifier to the automatic (remote) turn-on / turn-off lead of the
head unit.
15 „+12 V“ POWER INPUT TERMINAL
Terminal to connect the amplifier to the positive +12V pole of the car battery.
bobpbqbn
EA4160s
bm
21 3 4 5 6 7 8 9 bl
EA4160s
