this for each side.
• Whenre-installingthescrewsmakesuretorepeatthesamestepsofholdingthe
Pump Rods.
Pump Handle
• Usinga5/32"Allen wrench, removethetwoscrews located onthebackof the
Pump Plate.
• SlidethepumphandleoffthepumpguiderodandbecarefulnottolosethePump
Return Spring which is located inside the handle.
Pump Rods and Sled
• Once the Bolt and Pump Plate have been removed, the Pump Rod and Sled
assembly will slide off the back of the marker.
Hammer Assembly (Hammer,MainSpring,andRearAdjuster)
It is recommended that you do not remove the Hammer unless you feel confidant in
setting the Hammer Lug correctly.
• Usinga3/16"Allenwrench,removetheRearAdjusterandMainSpring.
• NextturntheHammerLugcounterclockwisewitha1/8”Allenwrenchuntilitiswithin
the bottom of the Hammer, thus visible thru the slot on the bottom of the body.
• TheHammerwillslideoutthebackofthemarkeriftheHammerLugishighenough
to create clearance.
Inline Regulator Assembly
• TurntheentireInlineRegulatorAssemblycounterclockwisetounscrewitfromthe
VerticalASA.
Pump Guide and Vertical ASA
• Usinga3/16"Allenwrench,turnthePumpGuidecounterclockwisetoremove.
• OncethePumpGuideisremovedtheVerticalASAwillslideoff the front of the
marker.
Valve Assembly (Valve,Cupseal,andValveSpring)
• TheValveAssemblyshouldonlyberemovedifmaintenanceisneededlikeanairleak.
• Oncethemarkerisfullydisassembledthevalveassemblycanbeaccessed.
• Removethevalvealignmentscrewfromthebottomofthebodyusingaflathead
screwdriver.
• InsertaPumpRodintothefrontofthebodyandpushthevalveassemblyoutthe
back of the marker.
10. STORAGE AND TRANSPORATION
IMPORTANT: Never carry your Empire marker uncased when not on a playing field.
The non-playing public and law enforcement personnel may not be able to distinguish
between a paintball marker and firearm. For your own safety and to protect the image
of the sport, always carry your Empire marker in a suitable marker case or in the box
in which it was shipped.
When you are finished using your Empire marker it is important that you prepare it
for storage. This will not only serve to increase the life of the marker, but will assure
optimum performance on your next outing.
• TheEmpiremarkermustbeclearofallpaintandairsourceswhennotbeingused.
• Besuretohavemarkerde-cockedandin“SafeMode”whennotinuse.
• Makesureabarrelblockingdeviceisinplace.
• StoreyourEmpiremarkerandpropellantincooldryplace.
• KeepyourEmpiremarkerawayfromunsupervisedchildren.
• YourEmpiremarkermustbefreeofallpaintandnotattachedtoapropellantsource
while being transported to and from the playing field.
• Observeandobeyalllocal,stateandfederallawsconcerningthetransportationof
paintball markers. For information concerning any of the laws in your area, contact
your local law enforcement.
• Always store the marker in a secure location when not in use so as to prevent
access by unauthorized persons.
