CLEANING AND LUBRICATING
To keep your machine running smoothly ;smoothly; it is necessary to clean using the brush from the
accessory box now and then.
This machine requires very little lubrication as the main components are made of special materials.
Occasionally, lubricate only the points illustrated.
SPECIFICATION OF MACHINE
Description
Specification
Number of threads
4 or 3
Number of needles
2 or 1
Sewing speed
1300 ± 200 r.p.m
Stitch width
4 - thread………..6 mm
3 - thread………..6 mm or 4 mm
Stitch length
1 ~ 5 mm
Lift of presser foot
4.0 mm
Needles
HA × 1 No. 11-14
130/ 705H No. 75 - 90
DimentionsDimensions
295 mm ( W) × 284 mm (D) × 295 mm (H)
Weight
5.5 kg (approx. 12 1bs.)
