Open the free arm for threading.
1. Remove the support bed as arrow.
2a. Press and pull up the free arm release lever.
2b. Pull up free arm as the arrow shows, then
the hinge will be released from needle plate.
USING THE MACHINE
[ HAND WHEEL ]
Always turn handwheel toward you, i.e. the
same direction as on a household sewing
machine.
[ FRONT COVER ]
To open front cover, slide the hollow to the right
as far as it will go then pull front cover toward
you.
[ FREE ARM ]
