8 Alphanumeric Display Indicators: -
There are two different types of Displays. There is the Vacuum Fluorescent Display (VFD)
type, which displays up to 80 characters, on a 4-line display. This is standard for 24 and
96 zone models.
A Liquid Crystal Display (LCD) type, is also available and is standard for 12 and 4 zone
models.
There are different types of conditions that are shown on the display, to suit different
circumstances. Below are some display indication screen shots: -
8.1 Non-Alarm Conditions:
Under Non-Alarm Conditions, the display
should show: -
The Green “Power” LED should also be illuminated.
8.15 Fire Event:
When a Fire event occurs the text on the display changes, to show: -
The above shows that Device 5 has generated a Fire event in Zone 1.
Status Normal
25/02/04 12:00
